DSJ 980

90cm Decorative Hood with EcoPower motor

REF. 40484821

EAN. 8421152157329

Select a colour: Stainless Steel

Up to 638 m³/h extraction capacity
3 extraction speeds
Push Botton control panel

Create harmony in your kitchen

Different shapes and sizes to find the perfect hood you are look for, with innovative designs in stainless steel or white/black glass.

Your hood always clean

Decorative filters with 12 layers ready to absorb up to 98% of grease and helping you to keep your hood clean. And you can wash the filters in the dishwasher.

Relax at home

Silent Ecopower engine features a powerful extraction capacity, with more than 800 m3, but it will keep your kitchen in silence, with just only 37dBA.

Maximum efficiency with lower consumption

Our hoods have 4A Energy Class so will reduce your next electric bill significantly.

Extraction from any angle

Teka hoods have optimal absorption capacity by extraction to enjoy your kitchen free of smoke and odors.

More powerful and environmentally responsible LED lighting

LED lighting bars is our best tool to provide light to a bigger area over the cooking zone, and being more efficient and environmentally friendly at the same time.

Ultraslim decorative hood
Push Buttons Control Panel
Operating Pilot Light
Conventional Aspiration Type
3 speeds
Exhaust capacities:
Free Outlet (m³/h): 638
Max. (m³/h): 614
Min. (m³/h): 268
Noise (LwA) Max Speed 66 dB
Noise (LwA) Min Speed 48 dB
Integrated LED Light
3 stainless Steel-aluminum Filter

Interior measurements

Inner Height (mm): 955

General measures

Product height (mm): 670-1000
Product width (mm): 900
Product depth (mm): 480
Net weight (Kg): 15,33

View technical drawing

Particular characterisitics

Type of hood: Horizontal
Style: Decoratives
Certificates: CE; CB; Rohs
Ø Outlet (mm): 150
Type of inner light: LED
Inside light Consumption (W): 1,5
Plug type: Schuko plug
Power rate (V): 230
Frequency (Hz): 50/60
Total hood power (W): 223
Number of motors: 1
Motor power (W): 220
Exhaust Capacity - Free Outlet (m3/h): 638

EU Regulation No. 65/2014 &66/2104

Annual energy consumption AEC kWh/annum (kWh): 96,7
Energy Efficiency Class: C
Fluid Dynamic Efficiency (FDEhood): 16,4
Fluid Dynamic Efficiency class: D
Light Efficiency (Lehood) lux/Watt: 31,7
Lighting Efficiency class: A
Grease Filtering Efficiency class: C
Air flow (Qmin) m3/h: 268
Air flow (Qmax): 614
Noise (LwA) Min Speed (dB): 48
Noise (LwA) Max Speed (dB): 66
Energy Efficiency Index (EEI): 81,5
Time increase factor: 1,4
Electric power input at best efficiency point (Wbep) W: 185,0
Nominal power of the lighting system (WL) W: 3
Average illumination of the lighting system on the cooking surface (Emiddle) Lux: 95

Accessories

Anti Return valve: Yes
Outlet reduction: Yes
Optional Charcoal Filter: D1C
Charcoal filter description: CHARCOAL FILTER D1C
Conventional recirculation kit (with tube cover): 40490150

Models

Number of filters: 3
Filter description: Stainless Steel filters
Control panel: Rectangular Push Buttons
Number of speeds: 4

Product Information Sheet - Delegated Regulation (EU) 65/2014

Supplier name or trademark: TEKA
Model identifier: DSJ 980
Annual Energy Consumption: 96,7
Energy Efficiency Class: C
Fluid Dynamic Efficiency: 16,4
Fluid Dynamic Efficiency class: D
Lighting Efficiency: 31,7
Lighting Efficiency class: A
Grease Filtering Efficiency class: C
Air flow (min speed normal use): 268
Air flow (max speed normal use): 614
Air flow (intensive or boost use): n.a
Airborne acoustical A-weighted sound power emissions (min speed normal use): 48
Airborne acoustical A-weighted sound power emissions (max speed normal use): 60
Power consumption in off mode (W): n.a
Power consumption in standby mode (W): n.a
