_Maestro

>

QUADRO DLV 998

Urban Colors Edition A++ Vertical hood with Countour rim system extraction in 90 cm

REF. 40437210
EAN. 8421152145692
Select a colour: Black
Black
  • Up to 815 m³/h extraction capacity
  • 3 air extraction levels + intensive
  • LED light bar
  • Class A++
  • EcoPower
  • Perimeter extraction
  • Extraction timer
  • Legally bound maximum A rating
  • Extremely silent (37dB min.)

Maximum efficiency with lower consumption

Our hoods have 4A Energy Class so will reduce your next electric bill significantly.
Maximum efficiency with lower consumption

Extraction from any angle

Teka hoods have optimal absorption capacity by extraction to enjoy your kitchen free of smoke and odors.
Extraction from any angle

More powerful and environmentally responsible LED lighting

LED lighting bars is our best tool to provide light to a bigger area over the cooking zone, and being more efficient and environmentally friendly at the same time.
More powerful and environmentally responsible LED lighting

Create harmony in your kitchen

Different shapes and sizes to find the perfect hood you are looking for, with innovative designs in stainless steel or white / black glass.
Create harmony in your kitchen

Your hood always clean

Decorative filters with 12 layers ready to absorb up to 98% of grease and helping you to keep your hood clean. And you can wash the filters in the dishwasher.
Your hood always clean
  • Vertical decorative hood
  • EcoPower motor
  • Energy Efficiency class: A++
  • Rim extraction
  • Touch control panel
  • Operating pilot light
  • 3 speeds + 1 intensive
  • Exhaust capacities:
  • Free Outlet, m³/h: 890
  • Qboost, m3/h: 815
  • Max., m3/h: 626
  • Min., m³/h: 264
  • Noise (LwA) Boost Speed, dB: 64,7
  • Noise (LwA) Max Speed, dB: 58,2
  • Noise (LwA) Min Speed, dB: 37,4
  • 1 LED bar
  • 2 Glass panel; aluminum filter below
  • Stop delay timer
  • Filter saturation indicator

Interior measurements

  • Inner Height (mm): 955

General measures

  • Product height (mm): 800-1200
  • Product width (mm): 900
  • Product depth (mm): 450
View technical drawing

Particular characterisitics

  • Air flow at best efficiency point (Qbep) (m3/h): 339
  • Certificates: CE; CB; Rohs
  • Noise (LwA) boost speed (dB): 65

EU Regulation No. 65/2014 &66/2104

  • Air flow (Qmax): 626
  • Noise (LwA) Max Speed (dB): 58
  • Energy Efficiency Class: A++
  • Fluid Dynamic Efficiency (FDEhood): 38,2
  • Off mode Power (Po) W: 0,32
  • Average illumination of the lighting system on the cooking surface (Emiddle) Lux: 390
  • Air flow at best efficiency point (Qbep) (m3/h): 339
  • Air flow (Qboost): 816
  • Fluid Dynamic Efficiency class: A
  • Electric power input at best efficiency point (Wbep) W: 100,0
  • Grease Filtering Efficiency class: C
  • Light Efficiency (Lehood) lux/Watt: 55,7
  • Time increase actor (f): 0,6
  • Lighting Efficiency class: A
  • Air flow (Qmin) m3/h: 264
  • Nominal power of the lighting system (WL) W: 7
  • Noise (LwA) Min Speed (dB): 37
  • Noise (LwA) Boost Speed (dB): 65

Accessories

  • Anti Return valve : Yes

Models

  • Stop delay timer : Yes
  • Filter saturation indicator : Yes
  • Inside Light (LED, Halogen, Incandescent): LED
  • Exhaust Capacity - Free Outlet (m3/h): 890
  • Filter description: Glass panel; aluminum filter below
  • Number of filters: 2
  • Filter - Aspiration Type: Rim extraction
  • Number of speeds: 3 + 1
  • Control panel: Touch control white display

Compatible accessories, not included in the product.
